Specification:

Sensor Resolution

960*640

Capacity

1D(EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codebar,industrial 2 of 5,Interleave 2 of 5,Matrix 2 of5,MSI,etc);

2D(PDF417,MICROPDF417,Datamxtrix,QR,Maxicode,Aztec,etc)

Depth of Field

Tested Code

Minimum

Maximum

5mil code39

1.5cm

8cm

13mil EAN13

4cm

23cm

15mil DM

3cm

14cm

15mil QR

2cm

13cm

15mil PDF417

6cm

18cm

System Compatibility

Android, IOS, Windows

Light Source

Wavelength,675nm3nm Infrared LED

Decode Accuracy

3mil

Code Available

1D,2D Codes printing on Paper or film on Cellphone

Scanning Speed

230 Times/Second

Symbol Contrast

20%

Scanning Angle

Horizontal : 72 Vertical:82 Rotated:360

Transmission range

The open space 15 meters

Wireless Technology

Bluetooth.

Drop

Design to withstand 1.5 M drops to concrete 300 TIMES

Environmental Sealing

IP54

Working Temperature

-20-55 Celsius degree

Conserve Temperature

-40-65 Celsius degree

Working/Conserve Humidity

5-95% Non-Condensed

Environment Light

0-120000LUX

Net Weight

145g

Packing Weight

330g

Host Size(L*W*H)

167mm* 72mm*85mm

Packing Size(L*W*H)

185mm*110mm*80mm

Prompting

Buzzer, Red & Blue LED

Battery capacity

2000MAH

Maximum Current

373MA

Working Current

168MA

Standby Current

72MA
