Overview:
Ugreen 60562 is a universal USB 2.0 to RS-485/422 serial port converter. It is compatible with USB 2.0, RS-422 and RS-485 standards without external power supply. It can convert single-ended USB signal into balanced differential RS-422 or RS-485 signal, ensuring that it is compatible with all existing communication hardware and communication hardware.

Ugreen 60562 supports RS422/RS485 serial port mouse, label printer, cash register, POS machine, scanner, etc. Balanced twisted pair length is inversely proportional to baud rate, and transmission distance can only be achieved max when the speed is below 100kb/s. In just a short distance, we can get the highest speed transmission. Generally speaking, the maximum transmission speed of 100m long twisted pair wire is only 1MB/s.

Specifications:

• Input:USB2.0A
• Output:DB9,malesusingwithterminals
• SerialPorts:RS422andRS485standards
• USBSignal:VCC,DATA+,DATA-,GND
• RS485Signal:T/R+,T/R-,GND
• RS422Signal:TSD+,TXD-,RXD+,RXD-,GND
• WorkingModes:Asynchronous;Point-to-PointorPoint-to-Multipoint;2-lineHalfDuplexand4-LineFullDuplex
• TransmissionDistance:1200m

Features:

• Maximum transmission rate: up to 1 Mbps
• Plug & Play after one-time driver installation
• Connect an RS-232 serial device such as a modem to a USB port on your computer
• Powered by USB port, no external power adapter needed
• Direction Control: Automatically identify and control data transmission direction by using ADDC technology
• Baud Rate: 300-921600bps, automatically detect serial signal rate
• Load Capacity: Support Point-to-Multipoint, every converter can connect 32 devices with RS422/RS485 port
